Molten metals simply slide off of the extra heavy duty coating of High-Temperature Silicone Rubber on all of these products (firesleeve), providing excellent burn-through protection.
Firesleeve (Eaton Weatherhead® Equivalent)
High Temperature, Heat, Flame, Fire, Pyro Resistant Silicone Rubber
Coated Fiberglass Sleeve & Jacket:
High Temperature, Heat, Flame, Fire, Pyro Resistant Silicone Rubber
Coated Fiberglass Sleeve & Jacket:
500°F / 260°C Continuous Exposure:
Higher Intermittent
Firesleeve (sometimes spelled fire sleeve or fire-sleeve) is the perfect sleeve and jacket choice for protecting industrial hydraulic hoses and lines, pneumatic lines, fuel & oil lines, brake lines, wires and cables from exposure to high temperature, heat, flame, fire and pyro exposure. The extra thick special formulation of silicone rubber on our firesleeve sheds molten metals, slag, welding splatter, electrical or grinding sparks and contamination. Firesleeve also provides protection from ozone, UV and abrasion.
The standard colour of firesleeve is red-oxide, but custom colours such as blue, grey, black, yellow and green are available; great for identifying hose and cable use when the sleeve is installed. Firesleeve is THE standard high-temperature and molten splash pyro protection jacket and sleeve for hose & cable.
Firesleeve is normally supplied in 50 & 100 foot lengths, but custom by-the-foot lengths are also available.
Higher Intermittent
Firesleeve (sometimes spelled fire sleeve or fire-sleeve) is the perfect sleeve and jacket choice for protecting industrial hydraulic hoses and lines, pneumatic lines, fuel & oil lines, brake lines, wires and cables from exposure to high temperature, heat, flame, fire and pyro exposure. The extra thick special formulation of silicone rubber on our firesleeve sheds molten metals, slag, welding splatter, electrical or grinding sparks and contamination. Firesleeve also provides protection from ozone, UV and abrasion.
The standard colour of firesleeve is red-oxide, but custom colours such as blue, grey, black, yellow and green are available; great for identifying hose and cable use when the sleeve is installed. Firesleeve is THE standard high-temperature and molten splash pyro protection jacket and sleeve for hose & cable.
Firesleeve is normally supplied in 50 & 100 foot lengths, but custom by-the-foot lengths are also available.
High Temperature Heat Flame Fire Resistant Firesleeve
The industrial grade of Firesleeve is fabricated from a knitted fiberglass yarn substrate, while the aviation grade Firesleeve is fabricated from a thicker and denser braided fiberglass yarn (Aviation grade Firesleeve meets AS1072, allowing qualified hose assemblies to pass testing to AS1055D specifications). For further information on the Aerospace grade of Firesleeve Click Here.
Industrial Firesleeve is available in sizes ranging from 0.25" Inside Diameter through 5" I.D. in 27 size steps.
Industrial Firesleeve is available in sizes ranging from 0.25" Inside Diameter through 5" I.D. in 27 size steps.
Firesleeve fire & pyro resistant sleeve and jacket withstands molten splash & welding splatter. Withstands 500°F / 260°C continuous exposure; 2200°F / 1205°C for periods up to 15 minutes and short flash excursions to 3000°F / 1650°C.
Firesleeve is highly flexible and conformable.
Firesleeve ends can be dipped in our SleeveSeal liquid silicone rubber end seal to prevent wicking of liquids and contamination.
A6900W SleeveSeal tape can be used to seal the ends of sleeve at the connector for a watertight seal. Also protects the clamp if used.
·
Part Number
S-FS & S-FSHD
S-FS & S-FSHD
Size (I.D.) Part Number Price per foot Available Length
0.50 A6908 $ 3.82 By-The-Foot or 100 foot box
0.63 A6910 $ 4.17 By-The-Foot or 100 foot box
0.75 A6912 $ 4.77 By-The-Foot or 100 foot box
0.88 A6914 $ 5.65 By-The-Foot or 100 foot box
1.00 A6916 $ 6.42 By-The-Foot or 100 foot box
1.25 A6920 $ 7.76 By-The-Foot or 100 foot box
1.50 A6924 $ 8.04 By-The-Foot or 100 foot box
1.75 A6928 $10.43 By-The-Foot or 100 foot box
2.00 A6932 $12.18 By-The-Foot or 100 foot box
2.25 A6936 $14.49 By-The-Foot or 100 foot box
3.00 A6948 $27.21 By-The-Foot or 100 foot box
See our catalog for other size of the same type of sleeve.
Sizes up to 2" ID also available in Black. Other colors may be available please enquire.
Firesleeve sealant tape A6900W 1" x 432 inches $33.80
0.50 A6908 $ 3.82 By-The-Foot or 100 foot box
0.63 A6910 $ 4.17 By-The-Foot or 100 foot box
0.75 A6912 $ 4.77 By-The-Foot or 100 foot box
0.88 A6914 $ 5.65 By-The-Foot or 100 foot box
1.00 A6916 $ 6.42 By-The-Foot or 100 foot box
1.25 A6920 $ 7.76 By-The-Foot or 100 foot box
1.50 A6924 $ 8.04 By-The-Foot or 100 foot box
1.75 A6928 $10.43 By-The-Foot or 100 foot box
2.00 A6932 $12.18 By-The-Foot or 100 foot box
2.25 A6936 $14.49 By-The-Foot or 100 foot box
3.00 A6948 $27.21 By-The-Foot or 100 foot box
See our catalog for other size of the same type of sleeve.
Sizes up to 2" ID also available in Black. Other colors may be available please enquire.
Firesleeve sealant tape A6900W 1" x 432 inches $33.80
